12V-24V Automotive Battery Tester Lead Acid Battery CCA Load Alternator Test Built-in Printer Truck Ship Motorcycle SUV Yacht ATV Battery Diagnosis Ge

EAN:
SKU: PSBA2000 12V-24V Automotive Battery Tester Lead Acid Battery CCA Load Alternator Test Built-in Printer Truck Ship Motorcycle SUV Yacht ATV Battery Diagnosis General cold start current detection

technical parameter
Auto Parts: Mr.Abbas
System voltage: 12 V, 24 V
Input voltage: 8V-30V
Working power supply: 8V-16V
Power supply requirements: No built-in battery is required
Capacity: Cold start Ampere (CCA), DIN, EN, IEC and battery ratings
Main control chip: APM32F103VCT6
Operating temperature: 0- + 50℃
Storage temperature: -20- - + 70℃
LCD: 128*64
Test lead: 100cm / 40in

major function
1. Tests 12V & 24V battery, cranking system, and charging system.
2. Supports all battery rating systems - CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, GB.
3. Displays test result in merely seconds, more accurate than the low-priced tester.
4. Tests in-vehicle battery and single storage battery.
5. Quick starter analysis without disabling the ignition.
6. Easy to use and read with large backlight LCD display and menu-driven operation.
7. Built-in thermal printer, easy to print test results
8. Clamps feature with reverse polarity protection without emitting light, heat, or spark for safe operation.
9. Support German, English, French, Dutch, Polish, Finnish and Italian
10. Product certification: CE FCC ROHS UKCA

measuring range
DIN/IEC: 100-1400
JIS: 26A17-245H52
CCA/BCI/CA/MCA/EN/SAE: 100-2000
GB: 30-220Ah

Product characteristics
Great Compatibility: PSBA1000 battery tester is designed for 12V and 24V lead-acid batteries with a capacity of 100 to 2000 CCA, including regular flooded, AGM flat plate, AGM spiral, gel, and deep cycle batteries. It covers most battery rating standards such as CCA, BCI, CA, MCA, JIS, DIN, IEC, EN, SAE, and GB.
Load Test & Charging Test: To tests the battery's start-up capability, maximum discharge capability and charging capability through the start-up load test, maximum working load test and charging test respectively. Please refer to the electronic manual below for a detailed description of the functions.
Built-in Thermal Printer: Equipped with a built-in thermal printer, it can print test data one-stop in a few seconds accurately, and you can share it with others for further analysis. No need for software and a PC connection to print, more convenient and faster.
Multiple Vehicle Applications: PSBA1000 battery tester is a more advanced tool with the capability to check 12V and 24V battery systems for automotive, marine, motorcycle, boat, truck, etc. Works on both in-vehicle battery and out-of-vehicle storage battery. It can also be used for analyzing starting system and charging system.
Fast Testing & Reliable Results: It adopts the advanced conductance testing technology to provide you with reliable results. Displays battery parameters in about 2.5 seconds to advise you if you need to replace the battery.
High-quality Services: We offers 30 days return & worry-free 12-month guarantee & friendly customer service. Welcome to contact our service team for technical support via Q&A and Email.

Product size: 25.3*7.2*5.1cm
Package size: 55.5*41*24.5cm
Package weight: 1,100 g
Quantity quantity: 20 pcs
Box weight: 14kg
