Automotive circuit system tester. Battery analyzer / circuit fault detection and diagnosis instrument

Details:

EAN:
SKU:PSP100(B0178). Automotive circuit system tester. Battery analyzer / circuit fault detection and diagnosis instrument
product description
Product material: ABS +
Product size: 160x50x40mm
Commodity weight: 800g
Product color: black
technical parameter
Detection system: onboard circuit / battery
Power supply voltage: 12-24 (V)
Operating temperature: -20-70℃
Specifications:
1. Display: TFT color display (160 x 128 dpi)
2. Operating temperature: 0 to 60°C (32 to 140F°)
3. Storage temperature: -40 to 70°C (-40 to 185F°)
4. External power supply: a 12.0 or 24.0 V power supply supplied through the vehicle battery
Test Tool Specification:
DC voltage range: 0-65V + 1 bit
Resistor range: 0-200 K ohms
Frequency response of the tone passing through
From 0Hz to 10 Khz.
circuit breaker
Rated current: 1-10 amps
testing standard:
100% current: no trip
150% current: trip within one hour
200% current: Trip in 3-30 seconds.
300% current: 0.5-4.0 sec.
Waterproof grade: IP67
Cable length: 6m
Battery life: 3-5 years
product function:
0V-65V electronic system, support for cars, trucks, motorcycles, ships
Voltage and Polarity Testing-Quick determination of the DC / AC voltage and voltage / negative voltage.
Resistance continuity test-The LCD display shows the value of the resistance.
AC circuit single test-quick solution to sensor circuit problems.
Handheld / vehicle or ground components are activated.
Check the bad ground contact and positioning short circuit
Product certification: CE, FCC, ROHS, UKCA
Supporting languages: English, Spanish, Dutch, French, Italian, Portuguese, Polish, Russian, Traditional Chinese, Simplified Chinese
Packaging information
Product volume: 28x18x9cm
product size:mm
packing measurement:mm
Product weight: 1.4kg
Binding specifications
PC/CTN
CTN SIZE: cm
G.W: kg
Package includes:
1pc x Probe adapter
1pc x Solid copper test probe ti
1pc x Extension connection line with alligator battery clip
1pc x User manual
